Alpine MRX-M110

1100W RMS, Monoblock Class D X-Power Series Car Amplifier
Alpine MRX-M110
  • MRX Series Monoblock Car Amplifier

  • RMS Power Rating(14.4V):

    • 4 ohms: 650 watts x 1 chan.

    • 2 ohms: 1100 watts x 1 chan.



  • MOSFET power supply

  • High efficiency digital circuit design

  • Remote bass level input (Alpine RUX-KNOB remote level control sold separately)

  • Variable Bass Boost (0 to +12 dB bass boost at 50 Hz)

  • Mono Channel operation

  • Speaker-level (high-level) inputs with signal sensing for automatic turn-on

  • Preamp RCA outputs to daisy chain multiple amps

  • 2-Way System Protection circuitry

  • Heavy duty heatsink for extreme heat dissipation

  • Nickel-plated RCA level inputs

  • Nickel-plated screw terminals

  • Input sensitivity:

    • Low level: 0.2V-4V

    • High level: 0.5V-10V



  • Variable low-pass filter (50-400 Hz, 12 dB/octave)

  • Subsonic filter (5-30 Hz, 24dB/octave)

  • Damping factor: >1000

  • CEA-2006 compliant amplifier

  • Frequency response: 5-400 Hz

  • Dimensions: 9"L x 13-3/8"W x 2-1/4"H

  • Price: $299
