Clarion EQS746

7-Band Equalizer
Clarion EQS746
  • 7-Band Rotary Equalizer
  • 12 dB Boost/Cut at 50 Hz, 125 Hz, 345 Hz, 750 Hz, 2.2 KHz, 6 KHz, and 16 kHz
  • Auxiliary Input with Source Select Switch
  • Adjustable Aux Input Sensitivity
  • Subwoofer Output Level Control
  • Gold-Plated Preamp Inputs and Outputs
  • Rotary Volume Control and Fader
  • 6-Channel RCA Outputs
  • Selectable 60/90 Hz Low-Pass Crossover
  • Crossover Slope: 12 dB/octave
  • Maximum Output Level: 7V RMS
  • Input Sensitivity: 50mV–4V RMS
  • Signal-To-Noise Ratio (S/N): 105 dB
  • Frequency Response: 10-50,000 Hz
  • Total Harmonic Distortion (THD): 0.005 %
  • Input Impedance: 10K Ohms
  • Output Impedance: 50K Ohms
  • Stereo Separation: 82 dB @ 1 kHz
  • Dimensions: 7" W x 1" H x 4" D

  • Price: $59
